Vertical drilling machine
Vertical drilling machine
Z5150B | XILI
Spindle speeds range 31.5rpm — 1400rpm
Max. drilling diameter 50mm
Working table size 560mm x 480mm
Price on request
See more
Vertical drilling machine
Vertical drilling machine
ZX-40HC | Wellon
Working table size 585mm x 190mm
Vertical drilling machine variation Round column vertical drilling machine
Max. drilling diameter 32mm / 40mm
Price on request
See more
Vertical drilling machine
Vertical drilling machine
Z5140 | WDM
Vertical drilling machine variation Square column vertical drilling machine
Travel of spindle quill 250mm
Max. drilling diameter 40mm
Price on request
See more
Radial Drilling machine
Radial Drilling machine
Z3080x25/1 | GoldCNC
Spindle speeds range 16rpm — 1250rpm
Max. drilling diameter 80mm / 100mm
Distance between spindle axis and column 500mm — 2500mm
Price on request
See more
Vertical drilling machine
Vertical drilling machine
Z5050V | WDM
Vertical drilling machine variation Round column vertical drilling machine
Spindle speeds range 50rpm — 2000rpm
Travel of spindle quill 240mm
Price on request
See more
Vertical drilling machine
Vertical drilling machine
Z5140B | WDM
Travel of spindle quill 250mm
Max. drilling diameter 40mm
Distance between spindle end and surface of worktable 335mm
Price on request
See more
Vertical drilling machine
Vertical drilling machine
Z5035A | WEIDA
Travel of spindle quill 150mm
Spindle speeds range 70rpm — 2600rpm
Max. drilling diameter 35mm
Price on request
See more
Vertical drilling machine
Vertical drilling machine
Z406B | KDE
Spindle speeds range 2000rpm — 12000rpm
Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine
Max. drilling diameter 6mm
Price on request
See more
Radial Drilling machine
Radial Drilling machine
Z3040x13/2 | WEIDA
Max. drilling diameter 40mm
Spindle speeds range 32rpm — 2500rpm
Distance between spindle axis and column 300mm — 1250mm
Price on request
See more
Radial Drilling machine
Radial Drilling machine
Z3063x20/1 | WEIDA
Spindle speeds range 20rpm — 1600rpm
Distance between spindle axis and column 450mm — 2050mm
Max. drilling diameter 63mm / 63mm
Price on request
See more
Vertical drilling machine
Vertical drilling machine
B16H | TOPTECH
Working table size 230mm x 245mm
Table stroke 495mm
Travel of spindle quill 65mm
Price on request
See more
Vertical drilling machine
Vertical drilling machine
B24H | TOPTECH
Spindle motor power 0.85kW / 50Hz
Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine
Max. drilling diameter 24mm
Price on request
See more
Radial Drilling machine
Radial Drilling machine
Z3040x16/1 | SMTCL
Max. drilling diameter 40mm
Spindle speeds range 25rpm — 2000rpm
Spindle motor power 3kW
Price on request
See more
Vertical drilling machine
Vertical drilling machine
B28H | TOPTECH
Spindle taper MT3
Spindle speeds range 120rpm — 4000rpm
Max. drilling diameter 28mm
Price on request
See more
Vertical drilling machine
Vertical drilling machine
Z4116A | KDE
Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine
Distance between spindle end and surface of worktable 95mm
Travel of spindle quill 100mm
Price on request
See more

Drilling machine (also known as drill press) is one of the most common type of machine tools in the machine shops. The drill machines are used for drilling, boring, countersinking, reaming, tapping and spotfacing.



Main types of drilling machines:

  • Vertical drilling machines are the most widely used in metalworking. They are used for making holes in small work-pieces in individual and small-lot production, also used in maintenance shops.
  • Radial arm drilling machine is a main machine tool for drilling operations in machine shops, designed for drilling large and heavy workpieces. This machine allows the operator to position the spindle directly over the workpiece without moving the workpiece to the tool.



Main types of drilling operations:

  • Tapping - is the process of creating threads on the inner surface of a drilled hole.
  • Spotfacing- is the process of furnishing finished circular surfaces around the top of a hole for seating the washer or the bolthead.
  • Reaming- is the process of making existing holes more dimensionally accurate for the improvement of the surface finish.
  • Countersinking- is a chamfering process around the top of a hole for holding the screw head or bolt below the surface of the drilled material.
  • Boring- is the process of enlarging an already drilled hole for the accommodation of the screw head.



We offer modern, reliable and well-priced drilling machines from China and Taiwan (R.O.C). Wide range of drilling machine tools: from small desktop vertical drillers for hobbies to heavy radial-arm drilling machines for large enterprises. Long-term warranty for machine tools, training, commissioning, warranty and post-warranty service, door-delivery to any region of world.
