Home / Machine tools and equipment / Metalworking machine tools / Milling machines / Knee-type milling machines / CNC Horizontal knee-type millling machine XK6032
WEIDA

CNC Horizontal knee-type millling machine XK6032

Series XK
Milling machine variation Horizontal milling machine
Working table size 1320mm x 320mm
Spindle speeds range 30rpm — 1500rpm

Price & Terms

Price on Request

Specifications

Basic feauturies

Milling machine variation Horizontal milling machine
Milling Horizontal

Horizontal worktable

Working table size 1320mm x 320mm
T-slots 3pcs / 18mm / 70mm
Max. weight of workpiece 320kg

Horizontal spindle

Spindle speeds range 30rpm — 1500rpm
Spindle taper ISO50
Spindle bore diameter 29mm
Distance from horizontal spindle axist to surface of working table 20mm — 370mm
Distance between spindle axis and ram 350mm
Spindle motor power 7.5kW

Feeds

Manual feed travels 800mm / 350mm / 280mm
Number of feed speeds No limitation
Min. speed of traverse feeds 6mm/min / 3mm/min / 6mm/min
Max. speed of traverse feeds 3200mm/min / 1600mm/min / 3200mm/min
Rapid traverse 4000mm/min / 2000mm/min / 4000mm/min
Torque of axis-drive motors 15N⋅m / 15N⋅m / 22N⋅m

Indication and control

Indication and control CNC
Model Fanuc 0i MF

Cutting fluid

Power of coolant pump motor 0.125kW

Engines and power supply

Voltage 380V / 50Hz

Overall dimensions and weight

Weight 2800kg
Overall length 1929mm
Overall width 2055mm
Overall height 1960mm

Equipment

Automatic centralized oil lubrication
Chip collector tray
Collets for milling chuck
Quantity: 1 set
Coolant system
Draw bar
Quantity: 1 pcs
Mill arbors
Quantity: 1 set
Milling chuck
Quantity: 1 pcs
ISO50
Oil gun
Quantity: 1 pcs
Outer arbor support for horizontal milling
Quantity: 1 pcs
Reduction sleeve
Quantity: 1 pcs
ISO50/MS4
Tools box
Quantity: 1 pcs
Лампа освещения рабочей зоны

Description

CNC Horizontal Knee-Type Milling Machine XK6032

Purpose:
Modern machine for high-precision metal processing, including:

  • Manufacturing of dies and molds
  • Production of forming tools
  • Milling of complex-shaped grooves
  • Processing parts in mechanical engineering, aircraft industry and defense sector

Key Features:

  • One-piece cast iron bed – increased rigidity and vibration resistance
  • Hardened guideways – high wear resistance and durability
  • Centralized lubrication system (electric pump) – smooth mechanism operation
  • Ball screws on X/Y/Z axes – smooth and precise positioning
  • Servo drives or stepper motors – excellent responsiveness and repeatability
  • Wide spindle speed range – compatibility with modern tools
  • Automatic axis feeds – convenient and precise machining
