Home / Machine tools and equipment / Grinding machines and tool-grinders / Grinding machines / Surface Grinding Machines / Surface Grinding Machine M7180
HDCNC

Surface Grinding Machine M7180

Working table size 1600mm x 800mm
Grinding wheel size 450mm x 203mm x 4063mm
Spindle motor power 15kW

Price & Terms

Price on Request

Specifications

Basic feauturies

Control PLC

Working table

Working table size 1600mm x 800mm
T-slots 3pcs / 22mm
Distance from spindle center line to surface of the table 725mm
Table rapid move speed 3m/min — 27m/min
Max. load 1600kg

Grinding stone

Grinding wheel size 450mm x 203mm x 4063mm
Grinding wheel rotation speed 1440rpm

Feeds

Table longitudinal travel (X-axis) 1700mm
Vertical movement by hand wheel 0.005mm / 0.515mm
Crossfeed handwheel 0.02mm

Accuracy

Best surface roughness 0.63μm/Ra

Engines and power supply

Total motor power 28.75kW
Spindle motor power 15kW
Rapid lifting motor 0.75kW
Hydraulic Power 5.5kW
Power of coolant pump motor 0.125kW
Crossfeed motor 0.75kW
Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 9500kg
Overall length 4800mm
Overall width 2500mm
Overall height 2650mm

Peripherals

Digital Readout Unit (DRO)

DRO SINO SDS6-2V
DRO SINO SDS6-2V
Quantity of controlled axis : 2pcs , Controlled axis : X-axis / Z-axis

Equipment

Balancer
✅
Balancing disk (Default)
Quantity: 1 pcs
✅
Coolant system (Default)
Diamond pen
Quantity: 1 pcs
✅
Grinding wheel (Default)
Quantity: 1 pcs
✅
Magnetic plate (Default)
Magnetic separator and paper filter
✅
Tools box (Default)
✅
Work area lighting lamp (Default)

Description

Surface Grinding Machine M7180

The machine is designed for high-performance machining of workpieces made of metal, cast iron, and other materials. It is an optimal solution for heavy-duty cutting, mass production, and repair operations in the automotive, machine-building, tooling, and die/mold industries.

Key Features:

  • High Power and Rigidity – Reinforced bed made of high-strength cast iron, optimized for heavy cutting loads and vibration damping.

  • Longitudinal Feed (Hydraulic) – Smooth table speed adjustment from 3 to 27 m/min.

  • Cross Feed of the Grinding Head – Precision ball screw drive: continuous feed (0.5–4.5 m/min) or rapid traverse (up to 400 mm/min).

  • Vertical Feed – Manual (handwheel graduation 0.005 mm) or motor-driven (rapid traverse 400 mm/min).

  • Enhanced Accuracy and Surface Finish – Achievable surface roughness Ra 0.63 µm.

  • Forced Lubrication Guideways – Extended machine service life.

  • Spindle – 1440 rpm, grinding wheel motor power – 15 kW.
