Shuangwei

Punching press JB04-2T

Series JB04
Control Manual
Type Electromechanical
Max. pressing force 3tn / 20kN
Slide stroke 40mm
Slider strokes number per minute 220times/min
Working table size 320mm x 300mm
Recalculating price…

Price & Terms

Price on Request

Specifications

Basic feauturies

Control
Manual
Type
Electromechanical

Capability

Max. pressing force
3tn / 20kN
Slide stroke
40mm
Slider strokes number per minute
220times/min
Closing height
240mm

Working area

Columns quantity
2pcs
Working table size
320mm x 300mm
Size of stem hole
25mm x 40mm
Space between tie bars
127mm

Engines and power supply

Motor power
0.45kW
Voltage
380V / 50Hz

Overall dimensions and weight

Weight
130kg
Overall length
520mm
Overall width
420mm
Overall height
710mm

Equipment

Remote controller
Set of stamps
Quantity: 1 set
✅
Tools box (Default)
Quantity: 1 pcs

Description

Key Advantages of the JB04-2T Press

• Compact benchtop dimensions — small size and weight of approximately 125 kg allow the equipment to be installed even in production spaces with limited area, in workshops and small workshops.

• Processing versatility — designed for a wide range of cold stamping operations: blanking, punching holes, bending, shallow drawing and ejection of stamped parts.

• Optimal productivity — provides up to 220 strokes per minute with a 40 mm stroke, enabling efficient serial operations without compromising quality.

• Sufficient force for small-batch production — nominal force of 20 kN (2 tons) is suitable for processing thin sheet metal, manufacturing fasteners and small parts.

• Convenient control — equipped with a foot pedal for the working stroke, ensuring operator safety and comfort during prolonged operation; modifications with two-button manual control are also available.

• Robust and reliable construction — crank mechanism with mechanical clutch and reinforced frame ensure stable operation and long service life of the equipment.

• Flexible adjustment — maximum die closing height of 160 mm and adjustable slide stroke allow the use of various types of tooling and dies.

• Energy efficiency — motor power consumption is only 370–450 W, reducing operating costs.

• Easy integration into production — operates from standard voltage 220 V / 380 V, 50 Hz, requiring no special power connections.

• Affordable price — belongs to the budget equipment category while maintaining acceptable build quality, making it attractive for small and medium-sized businesses.
