Single column single-blade block cutting machine

QZQ-1800 | WANLONG

Series: QZQ

Single column single-blade block cutting machine

Max. number of saw blades 1pcs
Stone-sawing machine type Single-blade / Single-column type
Range of Saw-blades diameters 1800mm
Control PLC
Cutting Vertical
Motor power 22kW

Price and terms

Price on request

Get Offer
* Price is based in standard configuration of machine. Click here for checking current configuration of machine.

Technical data

Basic feauturies
Stone-sawing machine type
Single-blade / Single-column type
Control
PLC
Cutting
Vertical
Capability
Max. workpiece dimensions
3000mm x 12000mm x 750mm
Main saw
Max. number of saw blades
1pcs
Range of Saw-blades diameters
1800mm
Recommended blade combination
Ф1800
Feed travels
900mm
Motor power
22kW
Engines and power supply
Voltage
380V / 50Hz / Three phase / AC
Total motor power
25.15kW
Overall dimensions and weight
Weight
3000kg
Overall length
6000mm
Overall width
2900mm
Overall height
3300mm
*Specifications are subject to change without notice.

Series

stanok QZQ-1200
stanok QZQ-1800
stanok QZQ-900
Basic feauturies
Stone-sawing machine type
Single-blade / Bridge-type
Single-blade / Single-column type
Single-blade / Bridge-type
Control
PLC
PLC
CNC
Cutting
Vertical
Vertical
Vertical
Capability
Max. workpiece dimensions
3000mm x 1600mm x 450mm
3000mm x 12000mm x 750mm
3000mm x 1600mm x 300mm
Main saw
Max. number of saw blades
1pcs
1pcs
1pcs
Range of Saw-blades diameters
1000mm — 1200mm
1800mm
600mm — 900mm
Recommended blade combination
—
Ф1800
—
Feed travels
500mm
900mm
500mm
Motor power
18.5kW
22kW
18.5kW
Engines and power supply
Voltage
380V / 50Hz
380V / 50Hz / Three phase / AC
50Hz
Total motor power
—
25.15kW
—
