Sunmill

Vertical CNC machining center JHV-2000

Series JHV
Working table size 2050mm x 900mm
Max. weight of workpiece 3000kg
Spindle cooling Oil cooling

Main Configuration

Spindle speeds range
6000rpm
10000rpm
Tool magazine capacity
24pcs
32pcs
Feed travels
2000mm / 900mm / 750mm
2000mm / 900mm / 1000mm

Price & Terms

Price on Request

Specifications

Basic feauturies

Machine frame Cast iron frame / Cast iron

CNC

CNC Fanuc 0i-MF Plus

Working table

Working table size 2050mm x 900mm
T-slots 6pcs / 18mm / 145mm
Max. weight of workpiece 3000kg

Spindle

Spindle cooling Oil cooling
Spindle taper BT50
Spindle motor power 15kW / 18.5kW
Spindle speeds range
6000rpm
10000rpm
Spindle drive
Belt drive
Direct drive
Distance from vertical spindle nose to surface of working table
150mm / 900mm
150mm / 1150mm

Automatic tool changer (ATC)

Tool changing type With robotic arm
Max. tool lenght 300mm
Max. tool weight 15kg
Tool magazine type
Drum-type tool magazine
Chain-type tool magazine
Tool magazine capacity
24pcs
32pcs
Max. tool diameter
220mm / 110mm
250mm / 125mm

Feeds

Max. speed of traverse feeds 10000mm/min / 10000mm/min / 10000mm/min
Rapid traverse 20000mm/min / 20000mm/min / 15000mm/min
Power of feed motors 7kW / 7kW / 7kW
X/Y guideways type Linear guidway
Z-axis guideway type Box guideway
X-axis transmission type Ball screw / Ø 50mm
Y-axis transmission type Ball screw / 50mm
Feed travels
2000mm / 900mm / 750mm
2000mm / 900mm / 1000mm

Cutting fluid

Through spindle coolant
Absence
Presence

Engines and power supply

Voltage 380V / 50Hz

Other

Lubrication system Full-automatic
Splash guard cover Full splash guard
Electrical cabinet
With heat exchanger
With aircondition

Overall dimensions and weight

Weight 18500kg
Overall length 5710mm
Overall width 4450mm
Overall height 3350mm

Peripherals

Tool measuring system

NC4 Renishaw
NC4 Renishaw
Tool measuring system : Renishaw NC4 , Repeatability accuracy : 0.001mm

Workpiece measurement system

OMP60 Renishaw
OMP60 Renishaw
Workpiece measurement system : Renishaw OMP60 , Repeatability accuracy : 0.001mm / 0.001mm / 0.001mm

Chip conveyors

CC-CT Turbo
CC-CT Turbo
Chip removal system : Chain type chip conveyor , Chip carrier : Presence
CC-ST Turbo
CC-ST Turbo
Chip removal system : Screw type chip conveyor , Chip carrier : Presence

Equipment

Air blow gun
CE specifications
Coolant gun
Coolant splash ring for spindle
Disc oil and coolant separator
M30 automatic power off system
Manual Pulse Generator (MPG)
Rigid tapping function
Spindle dust-proof air-sealing system
Status tower light
Tricolor
Tools box
Transformer
Wash down device
Work area lighting lamp
Х/Y/Z axis bellows

Description

JHV-1800/2000 — Heavy-Duty High-Performance CNC Machining Centers

Engineered for industrial environments demanding maximum precision, reliability, and productivity in the machining of large and heavy components. The JHV-1800/2000 series combines cutting-edge engineering, eco-conscious design, and a robust structure—making it the ideal solution for modern heavy-industry manufacturing.

Key Advantages:

Linear Guideways on X and Y Axes
Minimize friction and enable smooth, rapid table movement—enhancing both machining speed and cutting accuracy. The Z-axis features box-type sliding guideways, delivering superior rigidity and load-bearing stability.

High Positioning Speeds
Achieves rapid traverse rates of up to 20/20/15 m/min (X/Y/Z), significantly reducing non-cutting time and boosting overall productivity.

Eco-Friendly and Service-Friendly Enclosure
Designed with environmental and maintenance considerations in mind: separate oil and coolant channels minimize contamination and simplify workspace cleaning. An optional oil mist collector is available for enhanced air quality.

Reinforced Column with U-Shaped Base
The extended column span ensures exceptional stability when machining heavy workpieces, guaranteeing long-term durability even under the most demanding operating conditions.

FEA-Optimized Structure
The entire machine is engineered using advanced Finite Element Analysis (FEA). Its box-in-box structural design maximizes rigidity, vibration resistance, and long-term operational stability.

Ideal for:
• Heavy machinery manufacturing
• Production of large-scale components
• Machining of steel, cast iron, aluminum, and other demanding materials
