Vertical CNC machining center JHV-1600
Series
JHV
Working table size
1650mm x 750mm
Max. weight of workpiece
1200kg
Spindle cooling
Oil cooling
Tool magazine capacity
24pcs
Main Configuration
Spindle speeds range
10000rpm
12000rpm
15000rpm
Feed travels
1600mm / 750mm / 700mm
1600mm / 750mm / 850mm
Price & Terms
Price on Request
Specifications
Basic feauturies
Machine frame
Cast iron frame / Cast iron
CNC
CNC
Fanuc 0i-MF Plus
Working table
Working table size
1650mm x 750mm
T-slots
5pcs / 18mm / 150mm
Max. weight of workpiece
1200kg
Spindle
Spindle cooling
Oil cooling
Spindle motor power
11kW / 15kW
Spindle speeds range
10000rpm
12000rpm
15000rpm
Spindle drive
Belt drive
Direct drive
Spindle taper
BT40
BT50
Distance from vertical spindle nose to surface of working table
100mm / 800mm
100mm / 950mm
Automatic tool changer (ATC)
Tool magazine type
Drum-type tool magazine
Tool changing type
With robotic arm
Tool magazine capacity
24pcs
Max. tool diameter
150mm / 75mm
Max. tool lenght
300mm
Max. tool weight
7kg
Feeds
Max. speed of traverse feeds
15000mm/min / 15000mm/min / 15000mm/min
Rapid traverse
24000mm/min / 24000mm/min / 24000mm/min
Power of feed motors
4kW / 4kW / 7kW
X/Y guideways type
Linear guidway
Z-axis guideway type
Linear guidway
X-axis transmission type
Ball screw
Y-axis transmission type
Ball screw
Z-axis transmission type
Ball screw
Feed travels
1600mm / 750mm / 700mm
1600mm / 750mm / 850mm
Cutting fluid
Through spindle coolant
Absence
Presence
Engines and power supply
Voltage
380V / 50Hz
Other
Lubrication system
Full-automatic
Splash guard cover
Full splash guard
Electrical cabinet
With heat exchanger
With aircondition
Overall dimensions and weight
Weight
11000kg
Overall length
4680mm
Overall width
4070mm
Overall height
2970mm
Peripherals
Tool measuring system
NC4 Renishaw
Tool measuring system
: Renishaw NC4
,
Repeatability accuracy
: 0.001mm
Workpiece measurement system
OMP60 Renishaw
Workpiece measurement system
: Renishaw OMP60
,
Repeatability accuracy
: 0.001mm / 0.001mm / 0.001mm
Chip conveyors
CC-CT Turbo
Chip removal system
: Chain type chip conveyor
,
Chip carrier
: Presence
CC-ST Turbo
Chip removal system
: Screw type chip conveyor
,
Chip carrier
: Presence
Equipment
3-axes linear roller guideway
Air blow gun
CE specifications
Coolant gun
Coolant splash ring for spindle
Disc oil and coolant separator
M30 automatic power off system
Manual Pulse Generator (MPG)
Rigid tapping function
Spindle dust-proof air-sealing system
Status tower light
Tricolor
Tools box
Transformer
Wash down device
Work area lighting lamp
Х/Y/Z axis bellows
Description
JHV-1300 / JHV-1500 / JHV-1600 – Powerful and Compact CNC Machines for Demanding Applications
The ideal solution for businesses requiring high precision and reliability when handling heavy workloads. The JHV-1300/1500/1600 machines combine advanced engineering, an eco-friendly design, and a robust construction – the perfect choice for modern industrial manufacturing.
Key Advantages:
- Load Capacity: Four linear guideways on the Y-axis ensure stability when machining heavy workpieces.
- High Precision: The JHV-1600 models come standard with precision roller linear guideways on all 3 axes.
- Power & Stability: The reinforced Z-axis 7kW servo motor guarantees flawless operation without the need for a counterbalance system.
Ideal for:
- Heavy machinery manufacturing
- Production of large-sized parts
- Machining components from steel, cast iron, aluminum, and other materials
