Wellon

Band saw machine GH4250

Band saw machine type Double-column type
Workpiece dimensionsРазмер заготовки ■ 500mm x 500mm
Workpiece dimensions ⬤ 500mm
Workpiece clamping mode Hydraulic vise

Price & Terms

Price on Request

Specifications

Basic feauturies

Type Semi-automatic
Band saw machine type Double-column type

Capability

Workpiece dimensionsРазмер заготовки ■ 500mm x 500mm
Workpiece dimensions ⬤ 500mm
Workpiece clamping mode Hydraulic vise

Bandsaw

Saw blade size 5800mm / 41mm / 1.3mm
Saw blade speed 27m/min — 69m/min
Saw blade speed steps ranges 3pcs

Engines and power supply

Main saw motor power 5.5kW
Power of coolant pump motor 1.25kW
Motor power of hydraulic station 0.75kW

Overall dimensions and weight

Weight 2000kg
Overall length 3500mm
Overall width 1500mm
Overall height 2300mm

Equipment

Angle cutting
Automatic chip removal device
✅
Band saw blade (Default)
Quantity: 1 pcs
Blade breakage protection
✅
Blade protection covers (Default)
✅
Coolant system (Default)
✅
Drilling vice (Default)
Fast drop protection device
Feed roller table
Quantity: 1 pcs
1000mm
✅
Hydraulic blade tension (Default)
✅
Material support roller stand (Default)
Quantity: 1 pcs
1000mm
✅
Tension meter and laser device (Default)
✅
Tools box (Default)
Variable saw blade speed
✅
Work area lighting lamp (Default)
✅
Щетка для очистки полотна (Default)
Quantity: 1 pcs

Description

Key Advantages of the GH4250 Band Sawing Machine

  • Robust and Rigid Construction: The solid steel saw frame, guided by a dual-column system, ensures exceptional strength and high cutting stability.

  • Ergonomic Handling of Heavy Workpieces: The machine's low-profile design significantly simplifies the loading, unloading, and machining of large or heavy workpieces.

  • High Power and Flexible Adjustability: Equipped with a powerful 5.5 kW main motor and an adjustable feed rate, allowing optimal cutting parameters to be selected for various materials.

  • Automated Operating Cycle: Upon completion of the cutting cycle, the blade drive automatically stops, and the saw frame returns to its initial upper position, enhancing both safety and operational convenience.

  • Precision and Ease of Setup: The manual linear stop allows for quick and easy setting of the required workpiece length. The package also includes a blade tension meter and a laser positioning device for precise calibration.

  • Secure Material Clamping: A hydraulic workpiece clamping system (hydraulic vise) is included as standard, ensuring secure and safe material holding during operation.
