Manual Surface Grinder MG618A
The MG618A manual surface grinder is a high-precision and reliable machine tool designed for the finish machining of flat surfaces, slots, and steps.
Key Advantages:
High Rigidity and Vibration Resistance: The massive cast iron base and double-wall column structure effectively dampen vibrations and internal stresses, ensuring grinding process stability and machine longevity.
Precision Sliding Guideways: The cross feed of the saddle is realized on double V-shaped guideways with a Teflon soft belt. This significantly reduces friction, prevents the "stick-slip" effect, and improves positioning accuracy.
High-Precision Grinding Spindle: The spindle unit, featuring precision roller bearings and a sleeve-mounted design, guarantees minimal runout, allowing the machine to achieve a surface finish of up to Ra 0.16 μm and parallelism of 0.002 mm over a 300 mm length.
Feed Accuracy: The vertical feed with a handwheel graduation of 0.005 mm and the cross feed with a graduation of 0.02 mm allow the operator to perform ultra-precise material removal and control dimensions with the highest reliability.
Application Areas:
The MG618A machine is versatile and ideally suited for machining flat surfaces of ferrous and non-ferrous metal parts, as well as cemented carbides, where strict tolerances for flatness and parallelism are required.
