7-axis CNC spring coiling machine TK-708
WNJ
7-axis CNC spring coiling machine TK-708
Series
TK
Quantity of controlled axis
7pcs
Type of spring
Compression
Spring diameter
20mm
Wire diameter
0.15mm — 0.8mm
Price & Terms
Price on Request
Specifications
Basic feauturies
Quantity of controlled axis
7pcs
Type of spring
Compression
CNC
Spring coiling machine computer
HUST
CNC language
Chinese / English
Interactive programming
No
Yes
Processing parameters
Spring diameter
20mm
Wire diameter
0.15mm — 0.8mm
Wire feed value
0.01mm — No limitation
Wire feeding speed
120m/min
Direction of coiling
Right + Left
Wire feeding wheel pressing mode
Mechanical
Controlled axes
Outer diameter control mode
Two curves (individual motor control)
OD control axis
0.4kW / 0.4kW
Wire feed axis
0.75kW
Pitch axis
0.4kW
Arbor moving axis
0.4kW
Cutting axis
0.75kW / 0.75kW
Engines and power supply
Voltage
380V / 50Hz / Three phase / AC
Total motor power
3.85kW
Overall dimensions and weight
Weight
330kg
Overall length
950mm
Overall width
920mm
Overall height
1650mm
Peripherals
Wire feeders
✅
SLB-70
Diameter of feeding tray
: 650mm
,
Loading weight
: 70kg
,
Motor power
: 0.25kW
Spring length detector
WJVC-01
Spring detector
: Monochrome Industrial Camera
,
Spring lenght sorting device
: Presence
WJMP-01
Spring detector
: Spring length detector
,
Spring lenght sorting device
: Presence
Equipment
Infrared probe
✅
Left-direction coiling knife rest
(Default)
✅
Manual lubrication of guides
(Default)
✅
Pneumocylinder
(Default)
Quantity:
1 pcs
✅
Probe
(Default)
Quantity:
1 pcs
✅
Right-direction coiling knife rest
(Default)
✅
Status tower light
(Default)
✅
Tooling for coiling
(Default)
Quantity:
1 set
0.15mm / 0.2mm / 0.25mm / 0.3mm / 0.4mm / 0.5mm / 0.6mm / 0.7mm / 0.8mm
✅
Tools box
(Default)
✅
Work area lighting lamp
(Default)
Description
7-Axis CNC Spring Coiling Machine TK-708
High-precision CNC machine for producing springs with wire diameter from 0.15 to 0.8 mm. Equipped with 7 servo axes (Japanese motors). Designed for manufacturing compression springs of cylindrical, conical, or barrel shape.
Key Features:
7 axes — high flexibility for complex spring shapes
Operation without stopping — modify program and speed on the fly
Automatic protection — stops in case of wire break, no material, or malfunction
Maximum wire feed speed: 120 m/min
Independent servo motors control wire feed, cam, and pitch
Ensures high accuracy and repeatability during coiling
Applications: Production of precision springs for electronics, automotive industry, instrument engineering, and medical equipment.
