GWeike

Fiber laser cutting machine LF3015LN-II

Series LN
X/Y axis working travel 3030mm / 1520mm
Z axis working travel 105mm
No-load speed 0m/min — 80m/min
Positioning accuracy 0.03mm / 0.03mm
Calibration Automatic focus

Main Configuration

Laser power
6000W
3000W
Recalculating price…

Price & Terms

Price on Request

Specifications

Laser generator

Laser type
Ytterbium-droped fiber laser (YDFL)
Wavelength
1070nm
Laser power
6000W
3000W
Cutting thickness (stainless steel)
1mm — 20mm
1mm — 10mm
Cutting thickness (carbon steel)
1mm — 6mm
1mm — 4mm

Working table

Working table size
3050mm x 1530mm
Max. weight of workpiece
750kg
X/Y axis working travel
3030mm / 1520mm
Z axis working travel
105mm
No-load speed
0m/min — 80m/min
Max. acceleration
1.5g
Positioning accuracy
0.03mm / 0.03mm
Lubrication system
Full-automatic

Cooling

Cooling method
Liquid cooling

CNC

Model
FSCUT

Laser head

Calibration
Automatic focus

Engines and power supply

Voltage
380V / 50Hz / Three phase

Overall dimensions and weight

Weight
1700kg
Overall length
4480mm
Overall width
2100mm
Overall height
1460mm

Equipment

✅
Chiller (Default)
✅
Laser indicator (Default)
✅
Operational panel (Default)
✅
Safety guard (Default)
✅
Tools box (Default)

Description

Key Advantages of the LF3015LN Laser Cutting Machine

  1. High Performance and Processing Speed
    Maximum traverse speed reaches 80 m/min with acceleration up to 1G, ensuring fast and efficient cutting of metal sheets even in high-volume serial production.

  2. Excellent Positioning Accuracy
    Positioning repeatability of ±0.03 mm guarantees consistent cut quality and high manufacturing precision, even during extended operation.

  3. Versatile Laser Power Options
    The machine is available with various fiber laser power configurations—ranging from 350 W to 3000 W (optional)—allowing optimal setup selection for specific applications, from thin-sheet cutting to processing metal up to 25 mm thick and beyond.

  4. Robust and Reliable Construction
    The machine frame features a high-strength structure formed on a press and subjected to heat treatment, delivering lightweight design, corrosion resistance, and exceptional structural rigidity.

  5. Optimized Working Area
    The standard work envelope accommodates the majority of sheet metal cutting tasks, with extended configurations available for large-size workpieces.

  6. Material Versatility
    Designed for high-speed cutting of various metals, including stainless steel, carbon steel, aluminum, brass, copper, and other non-ferrous metals.

  7. Advanced Software Control
    Supplied with a professional CNC system offering convenient programming capabilities, precise cutting parameter control, and an intuitive operator interface.

  8. Energy Efficiency and Reliability
    Fiber laser technology delivers low power consumption compared to traditional laser systems, combined with a long service life of the laser source and minimal maintenance requirements.
