Jingye Machinery

Injection Stretch Blow Molding (ISBM) Machine WISBIII-110A

Series WISB
Material to be used PP / PETG / PET / PC / TRITAN / PPSU
Screw diameter 60mm
Theoretical shot volume 622cm³
Heating power 8kW
Clamping force of injection unit 1373.8kN
Clamping force of blowing unit 392.5kN
Recalculating price…

Price & Terms

Price on Request

Specifications

Basic feauturies

Material to be used
PP / PETG / PET / PC / TRITAN / PPSU
Machine drive
Servo-Hydraulic (Hybrid)

Injection Unit

Screw diameter
60mm
Theoretical shot volume
622cm³
Heating power
8kW

Clamping & blowing system

Clamping force of injection unit
1373.8kN
Clamping force of blowing unit
392.5kN
Heating power
19kW

Other

Air pressure
3MPa
Cooling Water Pressure
0.3MPa
Pump power
39kW + 30kW + 18kW

Overall dimensions and weight

Weight
15500kg
Overall length
5620mm
Overall width
2100mm
Overall height
3770mm

Equipment

Air compressor
Quantity: 1 pcs
Air Dryer
Quantity: 1 pcs
Chiller
Quantity: 1 pcs
Doser
Quantity: 1 pcs
Hopper dryer
Quantity: 1 pcs
Mold
Quantity: 1 pcs

Description

Key Advantages of the WISBIII-110A Injection Stretch Blow Molding Machine

Servo-Hydraulic (Hybrid) Drive System
Delivers high energy efficiency and precise control over all cycle stages—injection, oriented stretching, and blow molding—reducing both power consumption and scrap rates.

Optimal Injection Weight Range
Enables production of a wide variety of transparent PET/PETG bottles and containers without secondary processing steps, enhancing equipment versatility and reducing overall production complexity.

High Maximum Rotational Speed (up to 180 rpm)
Combined with optimized kinematics of stretching and blowing units, this ensures shorter cycle times and high productivity while maintaining consistent wall thickness and bottom quality of finished products.

Integrated Injection-Stretch-Blow Process in a Single Machine
Provides stable geometry for both molds and finished items, along with improved clarity and impact strength thanks to controlled polymer orientation in both axial and circumferential directions.

Machine Design Optimized for Transparent PET and PETG Processing
Ensures precise material dosing and plasticization, minimizing internal stresses and defects in the product wall for superior optical and mechanical properties.

Advanced Control System with Programmable Profiles
Features customizable settings for temperature, pressure, and speed parameters, simplifying process tuning for specific molds and products while reducing commissioning and changeover time.

Compact Layout and Integrated Operation
Consolidating all processes into one machine reduces floor space requirements, streamlines mold and product logistics, and lowers costs for auxiliary equipment compared to separate "injection + stretch-blow" production lines.
