Knee-type horizontal milling machine X6142
Price & Terms
Specifications
KDE X6142Basic feauturies
- Milling machine variation
- Horizontal milling machine
- Milling
- Horizontal
Horizontal worktable
- Working table size
- 1800mm x 420mm
- T-slots
- 3pcs / 18mm / 90mm
- Max. weight of workpiece
- 800kg
- Swivel angle
- -45° / 45°
Vertical spindle
- Spindle speeds range
- 30rpm — 1500rpm
- Spindle speed steps ranges
- 18pcs
- Spindle taper
- ISO50
- Distance from axis of vertical spindle to bed guideway
- 200mm
- Spindle motor power
- 11kW
Feeds
- Manual feed travels
- 1200mm / 360mm / 470mm
- Mechanical feed travels
- 1180mm / 350mm / 450mm
- Number of feed speeds
- 18pcs
- Min. speed of traverse feeds
- 22mm/min / 22mm/min / 8.3mm/min
- Max. speed of traverse feeds
- 1100mm/min / 1100mm/min / 410mm/min
- Rapid traverse
- 2400mm/min / 2400mm/min / 900mm/min
- Power of feed motors
- 3kW
Engines and power supply
- Voltage
- 380V / 50Hz
Overall dimensions and weight
- Weight
- 4200kg
- Overall length
- 2522mm
- Overall width
- 2262mm
- Overall height
- 2047mm
Peripherals
Digital Readout Unit (DRO)
Rotary tables
Dividing heads
Equipment
Description
Horizontal Knee-Type Milling Machine X6142
The X6142 horizontal knee-type milling machine is a high-performance, high-rigidity, universal metalworking equipment designed for a wide range of machining operations. It allows the use of face, cylindrical, disc, angular, and form milling cutters for the precise milling of flat and inclined surfaces, slots, grooves, and gears.
Key Advantages:
Reliable Hardened Transmission: The spindle and feed mechanisms operate on a high-precision hardened gear transmission. 18 spindle speed ranges (from 30 to 1500 rpm) allow for flexible selection of cutting parameters for various materials.
Overload Protection System: The spindle and feed drives are equipped with a safety clutch. In the event of a critical overload, the machine stops automatically, preventing tool breakage and damage to machine components.
Auto-Stop and Safety System: The feed mechanism is equipped with limit switches and an automatic stop function, allowing the operator to easily and safely change the direction of movement. The presence of a trimming handwheel significantly simplifies the machining of small parts and precise adjustments.
High Guideway Accuracy: The use of adjusting wedges (gibbs) on each guideway guarantees zero backlash and maintains high machining accuracy throughout the machine's entire service life.
Effective Lubrication System: An additional manual lubrication pump ensures a continuous supply of oil to all friction units, significantly extending the equipment's service life.
Extended Versatility: The overarm (bracket) design allows it to be retracted backward and a vertical milling head to be installed, expanding the machine's capabilities.
Application Areas:
The X6142 machine is highly versatile and is ideally suited for single-piece and small-batch production, as well as for repair and tooling operations.
