Luzhong

Pipe threading machine QK1313

Series QK13
Outer diameter of pipe 30mm — 126mm
Lathe bed width 550mm
Max. weight of workpiece 3000kg
Spindle bore diameter 130mm

Main Configuration

Max. swing diameter over bed
630mm
800mm
Max. swing over cross slide:
340mm
520mm
Recalculating price…

Price & Terms

Price on Request

Specifications

Capability

Outer diameter of pipe
30mm — 126mm
Distance between centers
1000mm
Lathe bed width
550mm
Max. weight of workpiece
3000kg
Max. swing diameter over bed
630mm
800mm
Max. swing over cross slide:
340mm
520mm

Headstock

Spindle speed steps ranges
3pcs
Spindle speeds range
30rpm — 800rpm
Spindle bore diameter
130mm
Spindle motor power
11kW

Feeds

Rapid traverse
4000mm/min / 6000mm/min
Power of rapid feed motors
0.3kW
X-Axis travel
340mm
420mm
Z-Axis travel
750mm
5750mm

Threading range

Range of inch threads
1T.P.I. — 14T.P.I.
Range of metric threads
1mm — 15mm

Lathe chuck

Chuck size
400mm
Chuck
3-jaw chuck
Clamping type
Mechanical

Carriage

Tool post
4-station turret toolpost
Tool shank
32mm x 32mm

Tailstock

Max. travel of tailstock quill
250mm
Tailstock quill diameter
100mm
Taper
MT6

Cutting fluid

Power of coolant pump motor
0.25kW

Overall dimensions and weight

Weight
4000kg
Overall length
3000mm
Overall width
1800mm
Overall height
1850mm

Equipment

✅
Automatic centralized oil lubrication (Default)
Chuck guard
Face plate
✅
High pressure coolant pump (Default)
Leadscrew guard
✅
Manual 3-jaws chuck (Default)
Quantity: 2 pcs
550mm
✅
Rear support bracket (Default)
Status tower light
Steady rest
✅
Taper turning attachment (Default)
Tool post guard
✅
Work area lighting lamp (Default)

Description

Key advantages:

1. High productivity in processing large-diameter pipes

  • The large 130 mm spindle bore combined with dual 400-mm three-jaw chucks enables efficient machining of large-diameter pipes without requiring additional fixtures or adapters.

  • The powerful 11 kW main spindle motor ensures stable operation under heavy cutting conditions and reliable threading of high-strength materials.

2. Exceptional accuracy and long-term stability

  • The one-piece cast bed made of high-strength cast iron with 550 mm guide width guarantees maximum structural rigidity and vibration resistance, even when machining long workpieces.

  • Ultrasonic frequency-quenched guideways (hardness HRC 60) together with Turcite B wear-resistant coating on carriage contact surfaces maintain precision throughout years of intensive operation.

3. Versatility in thread processing

  • The machine is capable of cutting all major types of pipe threads: metric, inch, module, DP (diametral pitch), and taper threads — making it indispensable for enterprises working with diverse pipe fittings and connections.

  • The 30–126 mm pipe threading range covers the vast majority of standards used in oil & gas, chemical, and mining industries.

4. Reliability and ease of operation

  • The automatic centralized lubrication system reduces maintenance labor and eliminates human error in guideway lubrication.

  • The built-in industrial heat exchanger for the electrical cabinet prevents electronic component overheating even during extended continuous operation in high-temperature environments.

5. Broad application scope

  • Specifically designed for oil & gas, mining, chemical piping, and geological prospecting industries — ideally suited for threading and reconditioning drill pipes, drill rods, and thread couplings under intensive operational conditions.
