YUHAI

Сold heading machine TBF-84S

Series TBF
Workpiece diameter 10mm
Max. length of workpiece 80mm
Production capacity 100pcs/min — 180pcs/min
Max. cut-off length 100mm
Main slide stroke 150mm
Recalculating price…

Price & Terms

Price on Request

Specifications

Basic feauturies

Workpiece diameter
10mm
Max. length of workpiece
80mm
Production capacity
100pcs/min — 180pcs/min

Processing parameters

Max. cut-off length
100mm

Working area

Main slide stroke
150mm
Main Die
60mm х 108mm
Punch die size
45mm х 115mm
Cut-off die
32mm х 20mm

Engines and power supply

Motor power
22kW

Overall dimensions and weight

Weight
13500kg
Overall length
3990mm
Overall width
2470mm
Overall height
1780mm

Equipment

Automatic counting device
✅
Machine equipment for workpiece forming (Default)
Quantity: 1 set
Material end detector
✅
Safety guard (Default)
Quantity: 1 pcs
✅
Wire decoiler (Default)
Quantity: 1 pcs
Русифицированная панель управления

Description

TBF-84S Cold Heading Machine

The TBF-84S cold heading machine is high-precision equipment for the cold forming of metal parts, such as fasteners, nuts, and specialized components.

1. High Productivity and Speed
The machine ensures rapid part production thanks to automated wire feeding and multi-stage cold heading. The processing speed reaches up to 180 parts per minute, significantly reducing the manufacturing time for large batches.

2. Dimensional Accuracy and Consistency
The equipment is equipped with precision dies and punches that ensure strict adherence to the geometric parameters of the parts. This eliminates the need for additional machining and reduces the defect rate.

3. Application Versatility
The machine supports working with various materials, including carbon and stainless steels, aluminum, and non-ferrous metal alloys. It can produce a wide range of products: from standard nuts to specialized fasteners.
