Xinsheng

Straightening and cutting machine GT-SF6

Series GT
Fuction Straightening / Cut-off
Wire diameter 2.0mm — 6.0mm
Processing length 50mm — 2000mm
Recalculating price…

Price & Terms

Price on Request

Specifications

CNC

CNC language
Chinese / English

Processing parameters

Fuction
Straightening / Cut-off
Wire diameter
2.0mm — 6.0mm
Processing length
50mm — 2000mm
Wire feeding speed
10m/min — 80m/min
Length tolerance
0.15mm

Engines and power supply

Motor power
9.0kW
Voltage
380V / 50Hz / Three phase

Overall dimensions and weight

Weight
950kg
Overall length
2450mm
Overall width
800mm
Overall height
1600mm

Peripherals

Wire feeders

✅
GT-DC200
GT-DC200
Type : Full-automatic , Loading weight : 200kg , Wire feeding speed : 10m/min — 80m/min

Equipment

Bars rack
Quantity: 1 pcs
✅
Operational panel (Default)
Quantity: 1 pcs
✅
Straightening steel rollers (Default)
Quantity: 1 set
✅
Tools box (Default)
Quantity: 1 pcs

Description

Straightening and Cutting Machine GT-SF-6

Purpose and Main Functions

  • The machine is designed for automatic straightening and cutting of metal wire.
  • It is used in production processes that require high precision and speed in processing metal workpieces for manufacturing complex-shaped parts.

Technical Specifications (Approximate)

  • Processable material: Metal wire (steel, stainless steel).
  • The equipment features high precision.
  • Control: Possible configuration with CNC for programming complex cutting and straightening tasks.

Design Features

  • A sturdy frame and structure ensure stability and reduced vibration during operation.
  • Process automation includes an automatic wire feeding and straightening system, minimizing operator involvement.
  • Compact dimensions are optimized for easy integration into production lines.

Industrial Applications

  • The machine is suitable for use in the automotive, construction, and metalworking industries, where precise wire cutting is required for manufacturing fasteners, reinforcement elements, and other parts.
