Vertical CNC machining center VMC1370
ZEYI
Vertical CNC machining center VMC1370
Series
VMC
Working table size
1360mm x 700mm
T-slots
5pcs / 18mm / 122mm
Max. weight of workpiece
1000kg
ATC
Presence / 24pcs
Feed travels
1300mm / 700mm / 600mm
Price & Terms
Price on Request
Specifications
Basic feauturies
Machine frame
Cast iron frame
CNC
CNC
Fanuc 0i-MF
Mitsubishi
SINUMERIK 828
Working table
Working table size
1360mm x 700mm
T-slots
5pcs / 18mm / 122mm
Max. weight of workpiece
1000kg
Spindle
Spindle drive
Belt drive
Spindle torque
20N⋅m
Distance from axis of vertical spindle to bed guideway
785mm
Distance from vertical spindle nose to surface of working table
80mm / 680mm
Spindle speeds range
8000rpm
10000rpm
Spindle taper
BT40
BT50
Spindle motor power
15kW
18.5kW
Accuracy
Positioning accuracy
0.005mm / 0.005mm / 0.005mm
Repeatability accuracy
0.003mm / 0.003mm / 0.003mm
Automatic tool changer (ATC)
ATC
Presence / 24pcs
Tool magazine capacity
24pcs
Feeds
Feed travels
1300mm / 700mm / 600mm
Rapid traverse
24mm/min / 24mm/min / 20mm/min
Overall dimensions and weight
Weight
10500kg
Overall length
3600mm
Overall width
3000mm
Overall height
3400mm
Description
VMC-1270 Vertical Machining Center
Key Advantages:
Structural rigidity has been further enhanced through optimization based on the finite element method (FEM), ensuring stable and high-quality production.
As one of its key components, the VMC-7370 is equipped with a 24-position tool magazine. The magazine offers large capacity, high rigidity, and maintains stability even under significant cutting loads.
The VMC-1370's control panel is designed with ergonomics in mind: intuitive operation, a clear and bright display, convenient and responsive buttons, and rich functionality—all creating comfortable, user-friendly, and efficient working conditions. Users can quickly master the machine and promptly increase productivity.
Ball screw drives, combined with high-speed movement and high-quality linear guides, ensure stability during the machining process.
