Home / Machine tools and equipment / Metalworking machine tools / Drilling machines / Vertical drilling machines / Vertical drilling machine Z4125D
WDM

Vertical drilling machine Z4125D

Series Z41
Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine
Design drilling machine
Max. drilling diameter 20mm / 25mm
Working table size 280mm x 300mm
Diameter of column 85mm

Price & Terms

Price on Request

Specifications

Basic feauturies

Vertical drilling machine variation Round column vertical drilling machine, Bench drilling machine
Design drilling machine

Capability

Max. drilling diameter 20mm / 25mm

Working table

Working table size 280mm x 300mm

Working area

Diameter of column 85mm
Distance between spindle axis and column 240mm
Distance between spindle end and working surface of basic plate 630mm
Distance between spindle end and surface of worktable 367mm

Headstock

Spindle speeds range 365rpm — 3150rpm
Spindle taper MT3 / MT2
Travel of spindle quill 125mm

Base

Base size 590mm x 375mm

Engines and power supply

Total motor power 1.1kW

Overall dimensions and weight

Weight 102kg
Overall length 495mm
Overall width 375mm
Overall height 850mm

Description

Machine Advantages:

  • High Precision & Stability: Improved structure ensures high machining accuracy, full functionality, and stable performance. Reduced maintenance for motor and drive belts.
  • Robust Construction & Options: Compliant with safety standards. Fitted with JJ-type safety gear, cooling control system, electrical outage protection. Special accessories optional. Multi-spindle models available.
  • Performance & Cost-Effectiveness: Enhanced productivity. Simplified tool change operation ("quick change"). High cost-effectiveness.
  • Two-Speed + VFD Control: Two-step pulley drive system combined with Variable Frequency Drive (VFD) enables stepless speed regulation and reversing function. Suitable for processing various materials and parts.
  • Pulley Upgrade for Versatility: Upgrade from original single-step pulley to two-step pulley allows easy switching between high-torque mode (for large hole drilling) and high-speed mode (for small diameter drilling). Eliminates the need for frequent removal of the belt guard for speed adjustment.
  • Centralized Control & Processing Quality: Ergonomically placed control buttons for ease of use. Main body parts milled. Key components (spindle) CNC machined, ensuring high precision, low noise, stability, and machine reliability.
  • Key Features:
    • Stepless Speed Regulation
    • Frequency Conversion & Reversing
    • Drilling & Tapping
