12-axis CNC spring forming machine CNC-1245
WNJ
12-axis CNC spring forming machine CNC-1245
Series
CNC
Quantity of controlled axis
12pcs
Spring-forming machine variation
Сamless machine
Wire diameter
2.0mm — 4.5mm
Price & Terms
Price on Request
Specifications
Basic feauturies
Quantity of controlled axis
12pcs
Type of spring
Tension / Torsion / Double torsion / Wire bending
Spring-forming machine variation
Сamless machine
CNC
Spring coiling machine computer
Windows based
CNC language
Chinese / English
Processing parameters
Wire diameter
2.0mm — 4.5mm
Direction of coiling
Right + Left
Wire feeding speed
75m/min
Wire feed value
0.01mm — 9999.999mm
Controlled axes
Sliders axis
8pcs x 2kW
Wire feed axis
1pcs x 5.5kW
Core axis
1pcs x 1kW
Wire rotary axis
2.7kW
Spinner
1.5kW
Engines and power supply
Total motor power
27kW
Voltage
380V / 50Hz / Three phase / AC
Overall dimensions and weight
Weight
3800kg
Overall length
2400mm
Overall width
2870mm
Overall height
2100mm
Peripherals
Wire feeders
✅
SLB-500
Type
: Full-automatic
,
Diameter of feeding tray
: 1750mm
,
Loading weight
: 500kg
,
Wire feeding speed
: 36m/min
,
Motor power
: 3kW
Equipment
Free arm station
✅
Pneumocylinder
(Default)
Quantity:
2 pcs
✅
Probe
(Default)
Quantity:
2 pcs
Servo cutter
✅
Tooling for coiling
(Default)
Quantity:
1 set
1.8mm / 3.5mm / 3.8mm / 4.0mm / 4.2mm / 4.5mm
✅
Tools box
(Default)
✅
Transformer
(Default)
✅
Work area lighting lamp
(Default)
Description
CNC-1245 key features:
- Windows operating interface simplifies the operation time and makes the operation more convenient
- Modular body design, highlighting the efficiency, stability, and ease of maintenance of each unit
- Controlled by twelve axes, expandable to sixteen axes, fast adjustment speed, can operate synchronously or in single steps
- Adopts one-piece casting high-precision wire feeding box to maintain the precision of wire feeding for a long time
Can produce special-shaped springs, wire forming, tension spring, compression spring, torsion spring, flat spring, scroll spring
