CNC Horizontal Lathe T46

Series T

Max. swing diameter over bed 400mm

Max Cutting Diameter 380mm

Processing length 300mm

Lathe chuck 152.4mm / Hydraulic

Main Configuration

CNC

Syntec 22TA

SINUMERIK 828

Fanuc 0i-TF Plus

Price & Terms

Price on Request

Specifications

Basic feauturies

CNC lathe type Slant-bed CNC lathe / 30°

CNC

Syntec 22TA

SINUMERIK 828

Fanuc 0i-TF Plus

Capability

Max. swing diameter over bed 400mm

Max Cutting Diameter 380mm

Processing length 300mm

Headstock

Spindle speeds range 4000rpm

Lathe Spindle Nose A2-5

Spindle bore diameter 56mm

Bar Size 45mm

Spindle torque 47.8N⋅m

Spindle motor power 7.5kW / 11kW

Lathe chuck

Lathe chuck 152.4mm / Hydraulic

Feeds

X-Axis travel 220mm

X-axis transmission type Ball screw / Ø 32mm

Z-Axis travel 350mm

Z-axis transmission type Ball screw / Ø 32mm

Rapid traverse 20000mm/min / 20000mm/min

Power of feed motors 1.8kW / 1.8kW

Carriage

Tool post Lathe turret

Number of stations 12pcs

Tool сhanging time (Tool-to-Tool) 0.3sec.

Engines and power supply

Total motor power 18kW

Voltage 380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight 3000kg

Overall length 1950mm

Overall width 1550mm

Overall height 1800mm

Peripherals

Chip conveyors

CC-CT Turbo

Chip removal system : Chain type chip conveyor , Chip carrier : Presence

Tool measuring system

HPMA Renishaw

Tool measuring system : Renishaw HPMA , Repeatability accuracy : 0.008mm

Workpiece measurement system

OLP40 Renishaw

Workpiece measurement system : Renishaw OLP40 , Repeatability accuracy : 0.001mm

Equipment

Air-conditioner for electrical cabinet

✅

Hydraulic Unit (Default)

Oil mist collector

Parts catcher

✅

Status tower light (Default)

✅

Tools box (Default)

✅

Work area lighting lamp (Default)

Description

T Series CNC Turret Lathe

Description:

The T Series CNC Turret Lathe is a modern solution designed for high-productivity machining of disk-type workpieces. The tailless configuration makes it ideal for automated production cells and dedicated machining lines.

Key Features & Advantages:

High Rigidity & Stability: A one-piece, premium cast iron bed provides superior vibration damping and minimal deformation, ensuring stability during heavy-duty cutting operations.
Slant Bed Design: The slanted bed offers excellent operator accessibility for loading and unloading workpieces and allows for efficient, uninterrupted chip removal.
High Productivity: Equipped with a servo-powered turret for fast and reliable tool changes, significantly reducing non-cutting time.
Specialized Application: Optimized for efficient roughing and finishing of a wide range of disk-type components.

Ideal For:

This machine excels in high-volume and mass-production environments, such as the automotive industry and general machinery manufacturing for disk-type parts.
