Surface Grinding Machine KGS510AHR

Key Features:

1. Purpose and General Characteristics:

Primary purpose: high-precision grinding of flat surfaces on workpieces. It enables machining with micron-level accuracy. Designed for processing parts made of steel, cast iron, and other materials.
The machine is recommended for high-precision machining of flat surfaces on various components.
It is part of a product line that includes models ranging from small-sized to large-sized, with varying levels of automation (from manual control to CNC).

2. Models and Control System:

Model KGS 510AHR: Longitudinal and cross table movements are automatic. The Z-axis (vertical) features a lifting drive.
Model KGS 510AHD: Longitudinal and cross table movements are automatic. Movement along the Z-axis is performed using a SIEMENS PLC controller with a touch panel.

3. Design Features:

Bed: Manufactured from high-quality cast iron, ensuring high rigidity and vibration resistance of the structure.
Workpiece Clamping: For reliable and stable clamping of the part on the worktable, an electromagnetic chuck is used.
