Taishin

Threading rolling machine TX-004

Series TX
Workpiece diameter 2mm — 3mm
Max. length of workpiece 25mm
Production capacity 200pcs/min — 300pcs/min
Recalculating price…

Price & Terms

Price on Request

Specifications

Basic feauturies

Workpiece diameter
2mm — 3mm
Max. length of workpiece
25mm
Moving Dies Stationary Length
20mm
Production capacity
200pcs/min — 300pcs/min
Motor power
1.5kW

Overall dimensions and weight

Weight
600kg
Overall length
1610mm
Overall width
1000mm
Overall height
1500mm

Equipment

Automatic counting device
Quantity: 1 pcs
✅
Loading plate (Default)
Quantity: 1 pcs
Material end detector
Quantity: 1 pcs
✅
Threading molds (Default)
Quantity: 1 set
✅
Tools box (Default)
Quantity: 1 pcs
Work area lighting lamp

Description

Key Advantages of the TX-004 Thread Rolling Machine

• Compactness and Mobility — Miniature dimensions and low weight allow the machine to be easily accommodated even in space-constrained production environments, and enable quick relocation between workstations when needed.

• Specialization in Miniature Fasteners — Optimized for thread rolling on miniature workpieces up to 25 mm in length, making it an ideal solution for producing micro screws, electronic fastenings, watchmaking components, and medical-grade fasteners.

• Waste-Free Cold Rolling Technology — Forms threads through plastic deformation without chip removal, eliminating production waste, enhancing joint strength, and preserving anti-corrosion coatings on the workpiece surface.

• Ease of Operation and Setup — An intuitive mechanical or semi-automatic control system enables operators without specialized training to quickly master machine operation and perform size changeovers in just a few minutes.

• Material Versatility — Suitable for processing workpieces made from soft and medium-carbon steels, brass, bronze, aluminum, and copper alloys, expanding application possibilities across diverse industrial sectors.
