Taishin

Threading rolling machine TX-3/16A

Series TX
Workpiece diameter 2mm — 5mm
Max. length of workpiece 50mm
Production capacity 120pcs/min — 200pcs/min
Recalculating price…

Price & Terms

Price on Request

Specifications

Basic feauturies

Workpiece diameter
2mm — 5mm
Max. length of workpiece
50mm
Moving Dies Stationary Length
50mm
Production capacity
120pcs/min — 200pcs/min
Motor power
4kW

Overall dimensions and weight

Weight
300kg
Overall length
930mm
Overall width
550mm
Overall height
1100mm

Equipment

Automatic counting device
✅
Loading plate (Default)
Quantity: 1 pcs
Material end detector
✅
Threading molds (Default)
Quantity: 1 set
✅
Tools box (Default)
Quantity: 1 pcs
Work area lighting lamp

Description

Key Advantages of the TAISHIN TX-3/16A Thread Rolling Machine

• High productivity — delivers an output of 120–140 parts per minute, enabling efficient serial production of fasteners.

• Optimal processing range — designed for rolling threads on blanks with diameters from 2 to 5 mm and maximum length up to 50 mm, including full-length threading over 50 mm.

• High-quality wear-resistant components — the feed bridge is made of 40Cr steel with high-frequency hardening and straightening, ensuring smooth material feeding and enhanced wear resistance.

• Robust construction with imported components — key units and parts are sourced from Taiwan, Germany, and Japan, guaranteeing stable operation and extended equipment service life.

• Operational cost efficiency — motor power consumption is only 4 kW despite high working speed, reducing energy costs per produced item.

• Compact footprint — machine dimensions of 1900×1050×1500 mm allow installation even in small production facilities without requiring significant floor space.

• Versatile application — suitable for manufacturing various fastener types: screws, self-tapping screws, drywall screws, and threaded nails.

• Standard tooling dimensions — uses dies sized 90×75×25 mm with a 55 mm mounting height, ensuring compatibility with common tooling and simplifying die replacement.

• Fully automated operation cycle — complete automation of the thread rolling process minimizes operator involvement and enhances consistency of finished product quality.

• Easy integration into production lines — the machine seamlessly integrates into complete fastener manufacturing lines following cold heading operations, enabling a continuous technological process.
