Punching press C1N-315H

Key advantages of the C1N-315H mechanical crank press (C-frame type):

• High structural rigidity: The all-welded or cast C-frame made of high-strength steel is designed for minimal deflection under load. This ensures operational stability and extends the service life of the dies.

• Precision accuracy: The use of high-precision slide guideways minimizes lateral play and tilt, guaranteeing high dimensional repeatability and superior quality of the stamped parts.

• Reliable clutch and brake system: Equipped with a modern dry pneumatic clutch and brake. Combined with responsive dual solenoid valves, this ensures instant engagement, a short slide stopping distance, and an enhanced level of operator safety.

• Ease of maintenance and setup: The open C-frame design provides wide access to the working area from three sides. This significantly simplifies and speeds up the processes of installing, aligning, and changing the die tooling.

• Hydraulic overload protection: The built-in hydraulic overload protection system automatically stops the slide and relieves pressure in the event that the nominal force is exceeded, protecting both the press itself and the expensive tooling from critical damage.

• Flexibility of technological settings: The availability of an adjustable shut height and the ability to select the slide stroke frequency mode (variable or fixed) allow the machine to be adapted to a variety of tasks, including blanking, bending, shallow drawing, and other operations.

• Efficient lubrication system: An automatic or semi-automatic circulating lubrication system for the main components (crankshaft bearings, guideways) reduces part wear, decreases operational noise, and extends maintenance intervals.
