GOANWIN

Punching press C1N-45V

Series C1N
Press type C-frame press
Max. pressing force 45tn / 450kN
Slide stroke 80mm
Working table size 400mm x 300mm x 60mm
Recalculating price…

Price & Terms

Price on Request

Specifications

Basic feauturies

Press type
C-frame press
Control
Semi-automatic
Type
Electromechanical

Capability

Max. pressing force
45tn / 450kN
Slide stroke
80mm
Slider strokes number per minute
180times/min
Closing height
250mm
Closing height adjustment
60mm

Working area

Distance from slider center to the side of column
120mm
Working table size
400mm x 300mm x 60mm
Workbench unloading hole size
38.1mm
Space between tie bars
280mm

Engines and power supply

Motor power
5.5kW
Voltage
380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight
3800kg
Overall length
1600mm
Overall width
950mm
Overall height
2500mm

Equipment

Die cushion
✅
Fastening bolts (Default)
Quantity: 1 set
Fast stamp change device
Foot brake
Quantity: 1 pcs
✅
Grease gun (Default)
Quantity: 1 pcs
Parts Ejector
Photoelectric protective device
Remote controller
Quantity: 1 pcs
Set of stamps
Quantity: 1 set
Status tower light
✅
Tools box (Default)
Quantity: 1 pcs
✅
Work area lighting lamp (Default)
Quantity: 1 pcs

Description

Key Advantages of the C1N-45 Mechanical Crank Press (C-Frame Type):

High Structural Rigidity: The fully welded or cast C-frame, constructed from high-strength steel, is engineered to minimize deflection under load. This ensures operational stability and extends die life.

Exceptional Precision: The use of high-precision ram guides minimizes lateral backlash and misalignment, ensuring excellent dimensional repeatability and high quality of stamped parts.

Reliable Clutch and Brake System: Equipped with a state-of-the-art dry pneumatic clutch and brake. Combined with highly responsive dual solenoid valves, this ensures instantaneous response, a short ram stopping distance, and enhanced operator safety.

Ease of Maintenance and Setup: The open C-frame design provides excellent three-sided access to the work area. This significantly simplifies and accelerates the installation, alignment, and replacement of die tooling.

Hydraulic Overload Protection: The integrated hydraulic overload protection system automatically stops the ram and relieves pressure if the nominal force (45 tons) is exceeded, protecting both the press and expensive tooling from critical damage.

Flexible Process Settings: Featuring an adjustable shut height (60 mm manual adjustment) and selectable ram stroke rate modes (variable or fixed), the machine can be easily adapted for a wide range of tasks, including blanking, bending, shallow drawing, and other operations.

Efficient Lubrication System: An automatic or semi-automatic circulating lubrication system for key components (crankshaft bearings, guides) reduces part wear, minimizes noise, and extends maintenance intervals.
