GUBEN

Surface Grinding Machine SG-52PC

Series PC
Control Semi-automatic
Working table size 520mm x 200mm
Max. load 210kg
Distance from spindle center line to surface of the table 470mm
Recalculating price…

Price & Terms

Price on Request

Specifications

Basic feauturies

Control
Semi-automatic

Working table

Working table size
520mm x 200mm
Max. load
210kg
Distance from spindle center line to surface of the table
470mm
T-slots
1pcs / 14mm
Table rapid move speed
3m/min — 25m/min
0.5m/min — 20m/min

Headstock

Spindle speeds
3500rpm

Grinding stone

Grinding wheel size
255mm x 50.8mm x 25mm

Accuracy

Machining Accuracy
0.002mm / 300mm
Best surface roughness
0.08μm/Ra

Engines and power supply

Main motor power
4kW
Rapid lifting motor
0.85kW
Hydraulic Power
1.5kW
Power of coolant pump motor
0.18kW
Crossfeed motor
0.85kW
Voltage
380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight
2250kg
Overall length
2700mm
Overall width
2200mm
Overall height
2200mm

Equipment

Balancer
✅
Coolant system (Default)
Diamond pen
✅
Grinding wheel (Default)
Magnetic plate
Quantity: 1 pcs
500×200mm
Magnetic separator and paper filter
✅
Tools box (Default)
Quantity: 1 pcs
✅
Work area lighting lamp (Default)
Quantity: 1 pcs

Description

Key Advantages of the SG-52PC Surface Grinding Machine

1. High Machining Accuracy

  • Surface parallelism: 0.002 mm

  • Achievable surface roughness: Ra 0.08 µm

2. Automation and Versatility

  • Multiple grinding programs: semi-automatic, automatic, groove cutting, and slotting

  • Machining of grooves with varying depths and widths

  • Various plunge grinding strategies: left, right, both sides, and Z-shaped

3. Intelligent Grinding Wheel Dressing System

  • Coordinated dressing of the wheel's bottom face and side edges

  • Automatic grinding wheel wear compensation within the machining program

  • Configurable automatic dressing cycle start or forced manual dressing

4. Constant Surface Speed (CSS) Function

  • Automatic spindle speed increase as the wheel diameter decreases

  • Maintains optimal grinding surface speed

  • Ensures consistent surface quality throughout the entire lifespan of the wheel

5. User-Friendly Control and Operation

  • Drop-down menu for quick adjustment of feed parameters

  • Table travel limit input via teaching mode

  • Real-time display of program execution status and informational messages

  • Customizable parameter settings

  • Self-diagnostic function for fault detection

6. Compact Footprint with High Productivity

  • Compact dimensions: 2700 × 2200 × 2200 mm

  • Optimal balance of productivity and floor space
