GUBEN

Surface Grinding Machine SG-52PC2

Series PC
Control Semi-automatic
Working table size 520mm x 200mm
Max. load 210kg
Distance from spindle center line to surface of the table 470mm
Recalculating price…

Price & Terms

Price on Request

Specifications

Basic feauturies

Control
Semi-automatic

Working table

Working table size
520mm x 200mm
Max. load
210kg
Distance from spindle center line to surface of the table
470mm
T-slots
1pcs / 14mm
Table rapid move speed
3m/min — 25m/min
0.5m/min — 20m/min

Headstock

Spindle speeds
3500rpm

Grinding stone

Grinding wheel size
255mm x 50.8mm x 25mm

Accuracy

Machining Accuracy
0.002mm / 300mm
Best surface roughness
0.08μm/Ra

Engines and power supply

Main motor power
4kW
Rapid lifting motor
0.85kW
Hydraulic Power
1.5kW
Power of coolant pump motor
0.18kW
Crossfeed motor
0.85kW
Voltage
380V / 50Hz / Three phase / AC

Overall dimensions and weight

Weight
2250kg
Overall length
2700mm
Overall width
2200mm
Overall height
2200mm

Equipment

Balancer
✅
Coolant system (Default)
Diamond pen
✅
Grinding wheel (Default)
Magnetic plate
Quantity: 1 pcs
500×200mm
Magnetic separator and paper filter
✅
Tools box (Default)
Quantity: 1 pcs
✅
Work area lighting lamp (Default)
Quantity: 1 pcs

Description

Key Advantages of the SG-52PC2 Surface Grinding Machine

The PC2 series machines utilize precision linear guideways instead of sliding guideways, delivering twice the precision in minimum feed (0.5 µm vs. 1.0 µm for the PC series) and eliminating backlash during reversal, making the machine ideal for ultra-precision grinding.

1. High Machining Accuracy

  • Surface parallelism: 0.002 mm

  • Achievable surface roughness: Ra 0.08 µm

2. Automation and Versatility

  • Multiple grinding programs: semi-automatic, automatic, groove cutting, and slotting

  • Machining of grooves with varying depths and widths

  • Various plunge grinding strategies: left, right, both sides, and Z-shaped

3. Intelligent Grinding Wheel Dressing System

  • Coordinated dressing of the wheel's bottom face and side edges

  • Automatic grinding wheel wear compensation within the machining program

  • Configurable automatic dressing cycle start or forced manual dressing

4. Constant Surface Speed (CSS) Function

  • Automatic spindle speed increase as the wheel diameter decreases

  • Maintains optimal grinding surface speed

  • Ensures consistent surface quality throughout the entire lifespan of the wheel

5. User-Friendly Control and Operation

  • Drop-down menu for quick adjustment of feed parameters

  • Table travel limit input via teaching mode

  • Real-time display of program execution status and informational messages

  • Customizable parameter settings

  • Self-diagnostic function for fault detection

6. Compact Footprint with High Productivity

  • Compact dimensions: 2700 × 2200 × 2200 mm

  • Optimal balance of productivity and floor space
