GUBEN

Surface Grinding Machine SG-73PC

Series PC
Control Semi-automatic
Working table size 720mm x 300mm
Max. load 400kg
Distance from spindle center line to surface of the table 630mm
Recalculating price…

Price & Terms

Price on Request

Specifications

Basic feauturies

Control
Semi-automatic

Working table

Working table size
720mm x 300mm
Max. load
400kg
Distance from spindle center line to surface of the table
630mm
T-slots
1pcs / 14mm
Table rapid move speed
3m/min — 25m/min
0.5m/min — 20m/min

Headstock

Spindle speeds
2300rpm
3000rpm

Grinding stone

Grinding wheel size
400mm x 127mm x 40mm

Accuracy

Machining Accuracy
0.002mm / 300mm
Best surface roughness
0.08μm/Ra

Engines and power supply

Hydraulic Power
1.5kW
Power of coolant pump motor
0.18kW
Voltage
380V / 50Hz / Three phase / AC
Main motor power
5.5kW
7.5kW
Rapid lifting motor
0.85kW
1.0kW
Crossfeed motor
1.0kW
0.85kW

Overall dimensions and weight

Weight
3450kg
Overall length
3500mm
Overall width
2600mm
Overall height
2300mm

Equipment

Balancer
✅
Coolant system (Default)
Diamond pen
✅
Grinding wheel (Default)
Magnetic plate
Quantity: 1 pcs
700×300mm
Magnetic separator and paper filter
✅
Tools box (Default)
Quantity: 1 pcs
✅
Work area lighting lamp (Default)
Quantity: 1 pcs

Description

Key Advantages of the SG-73PC Surface Grinding Machine

1. High Machining Accuracy

  • Surface parallelism: 0.002 mm

  • Achievable surface roughness: Ra 0.08 µm

2. Automation and Versatility

  • Multiple grinding programs: semi-automatic, automatic, groove cutting, and slotting

  • Machining of grooves with varying depths and widths

  • Various plunge grinding strategies: left, right, both sides, and Z-shaped

3. Intelligent Grinding Wheel Dressing System

  • Coordinated dressing of the wheel's bottom face and side edges

  • Automatic grinding wheel wear compensation within the machining program

  • Configurable automatic dressing cycle start or forced manual dressing

4. Constant Surface Speed (CSS) Function

  • Automatic spindle speed increase as the wheel diameter decreases

  • Maintains optimal grinding surface speed

  • Ensures consistent surface quality throughout the entire lifespan of the wheel

5. User-Friendly Control and Operation

  • Drop-down menu for quick adjustment of feed parameters

  • Table travel limit input via teaching mode

  • Real-time display of program execution status and informational messages

  • Customizable parameter settings

  • Self-diagnostic function for fault detection

6. Compact Footprint with High Productivity

  • Compact dimensions: 3500× 2600× 2300mm

  • Optimal balance of productivity and floor space
